TI 250
| IMAGING PERFORMANCE | |
| Detector | New UFPA microbolometer (384x288 pixels, 25μm) |
| Spectral range | 8 ~ 14μm |
| Thermal sensitivity | <65mK at 30°C |
| Field of view | 21° x 15° |
| Lens | 15mm |
| Spatial resolution | 2.3mrad |
| Focus | manual |
| Image frame rate | 50/60Hz |
| Electronic zoom | 2x |
| IMAGE PRESENTATION | |
| Display |
3.5° color LCD, readable in sunlight |
| Video output | PAL/NTSC |
| MEASUREMENT | |
| Temperature range | -20 ~ 120°C (-4° ~ 248°F) 0 ~ 350°C (32° ~ 662°F) 350 ~ 1200°C (662° ~ 2192°F) (option) |
| Accuracy | ±2°C or ±2% (reading range),whicever is greater |
| Measurement modes | 4 moveable spots; 3 moveable areas displaying either max, min & avg; vertical & horizontal line profile; isothermal analysis; temperature difference; temperature alarm |
| Display color | 12 palletes available |
| Temperature unit | °C, °F, or K selectable |
| Emissivity correction | Adjustable from 0.01 to 1.00 |
| Ambient temperature correction |
Auto, accroding to background temperature input |
| Optics transmission correction |
Auto, according to distance, relative humidity, ambient temperature input |
| IMAGE STORAGE | |
| Type | Built-in memory |
| File format | JPEG, with 14 bits measure data |
| Image storage | up to 1000 images |
| Vioce annotation | 40 seconds voice recording per image (built-in microphone) |
| INTERFACES | |
| Communication | USB |
| LASER LOCATOR | |
| Classification type | Class 2, 1mW/635nm Red |
| POWER SYSTEM | |
| Battery type | Rechargeable Li-ion battery |
| Battery operating time |
3 hours (under normal temperature) |
| Charging system | Intelligent charging |
| External power | 12V±5% DC |
| ENVIRONMENTAL | |
| Operating/storage temperature |
-40 ~ 70°C (-40 ~ 158°F) |
| Operating/storage humidity |
≤90%, non considering |
| Encapsulation | IP54 |
| PHYSICAL CHARACTERISTIC | |
| Size | 330 x 95 x86mm |
| Weight | 650g |
| ACCESSORIES | |
| Standard accessories | 2 Li-ion rechargeable battery, smart battery charger (international converter), USB cable, software & manual CD, warranty card, certificate of conformance |
| Options | In built wide angle lens (30°x23°/10mm), in built tele lens (9°x6°/80mm). high temperature lens converter, extra li-ion battery |
